Damper Service
200 Hour Service Damper Service
Remove the compression damper o-rings and discard them.
Apply grease to new o-rings and install them.
Remove the bottom bolt.
Remove the seal head.
Clean the damper shaft and inspect the shaft for scratches.
NOTICE
Scratches on the shaft can cause oil to leak. If a scratch is visible, the
rebound damper may need to be replaced.
1
2
