33
Damper Removal
Pull the rebound shaft to full extension.
Remove the rebound damper and seal head.
Clean the inside and outside of the upper tube.
Inspect the inside and outside of the upper tube for scratches.
NOTICE
Scratches on the inside surface of the upper tube can cause oil to
leak. If an internal scratch is visible, the crown steerer upper tube
assembly may need to be replaced.
6
7
8
To Next Page
