SRAM RockShox SEKTOR

40
Compression Damper Installation
Thread the top cap into the upper tube and tighten it.
RL: Apply grease to the top cap detents and detent spring.
RL: Install the adjuster knob with the tab in the 7-8 o'clock, unlocked
position.
Install and tighten the retaining screw.
4
24 mm 12.4 N·m (110 in-lb)
5
Grease
6a
RL
2.5 mm
2.5 mm 1.4 N·m (12 in-lb)
