25Piston Assembly Installation
Align the holes of the SwingLink™ and the SwingLink bushings, then
press the pivot pin into the hole until it is flush with the lever body.
Apply a small amount of Loctite® Threadlocker Blue 242® onto the
pinch bolt.
Use a T8 TORX® wrench to thread the SwingLink pinch bolt into the
lever body. Use a torque wrench and a T8 TORX® bit socket to torque
the bolt to 2.7-3.2 N·m (24-28 in-lb).
10
11
Loctite® Threadlocker Blue 242® 20 mm or 15 mm Thru Axle
T8 TORX wrench QR
T8 TORX bit 2.7-3.2 N•m (24-28 in-lb) 22 mm
