LAMP
14-4
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
REMOVING HEADLAMP HOUSING
1. Disconnect the negative cable
on the battery.
2. Unscrew the two bolts and
carefully remove the lower
headlamp cover.
4. Disconnect the two headlamp
connectors and remove the
headlamp housing.
3. Unscrew the bolt at the bot-
tom of the headlamp.
Headlamp
high beam
Headlamp
low beam
Turn signal
lamp
Cap
Cap
For safe driving, do not adjust the headlamp aiming by yourself.
It should be done by a qualified technician in a Ssangyong
Dealer or Ssangyong Authorized Service Center.
WARNING
