PIC.34
NORMAL
-6-
TEST THE RADIO CONTROL SYSTEM
1、Switch on the transmitter and connect the battery to airplane as above steps.
2、Test the power system and the RMS:
NORMAL mode:RMS will unfold from the fuselage if the transmitter mode is on the
“ NORMAL” mode (PIC.34,PIC.35).
(1)、Push the throttle stick and its trim to the min(PIC.36),propeller should be stopped
completely(PIC.37).
(2)、Upward the throttle stick slowly(PIC.38), the speed of prop will faster gradually
(PIC.39).
NOTE : If the motor doesn't work when you upward the throttle,please check the battery
capacity.
PIC.30
5、Test fit the canopy hatch into the fuselage as picture show
(PIC.31). It is important to make sure the battery hatch
attached tightly to avoid falling off during the flight
(PIC.32,PIC.33).
WARNING :
to stop the propeller or the movement of RMS by hand or anything else.
Keep everything clear of the propeller once the battery is plugged in. Do not try
PIC.36
PIC.37 PIC.39PIC.38
PIC.31
PIC.32
PIC.33
X
PIC.35
⑵、Fit the battery in its place as shown. Otherwise, The plane will lose its balance
potentially because of the movement of the battery.
