Quick start UM2408
10/51 UM2408 Rev 2
5 Quick start
The STM32H7 Nucleo-144 board is a low-cost and easy-to-use development kit, used to
evaluate and start development quickly with an STM32H7 microcontroller in LQFP144
package.
Before installing and using the product, accept the Evaluation Product License Agreement
from the www.st.com/epla web page. For more information on the STM32H7 Nucleo-144
and for demonstration software, visit the www.st.com/stm32nucleo
web page.
5.1 Getting started
Follow the sequence below to configure the Nucleo-144 board and launch the
demonstration application (For components location, refer to
Figure 4):
1. Check the JP2 (5 V) position (Refer to Section 6.4). Make sure JP4 (IDD) is selected
(Refer to Section 6.8) and make sure JP5 (1.8 V / 3.3 V) is correctly configured (Refer
to Section 6.4.9)
2. For the correct identification of the device interfaces from the host PC and before
connecting the board, install the Nucleo USB driver available on the
www.st.com/stm32nucleo website.
3. Power the board by connecting the STM32H7 Nucleo-144 board to a PC with a USB
cable ‘Type-A to Micro-B’ through the USB connector CN1 on the ST-LINK. As a result,
the green LED LD5 (PWR) and LD4 (COM) light up and the red LED LD3 blinks.
4. Press button B1 (Left button).
5. Observe the blinking frequency of the three LEDs LD1 to LD3 changes, by clicking on
the button B1.
6. The software demonstration and the several software examples, that allow the user to
use the Nucleo features, are available at the www.st.com/stm32nucleo web page.
7. Develop an application, using the available examples.
