6.2 Mechanical drawing

Figure 6. STM32H5 Nucleo-144 board mechanical drawing (in millimeters)

DT59087V1

133.34 mm

70.00 mm

UM3115

Mechanical drawing

UM3115 - Rev 1

page 10/43
