ST STM32L053 - Hardware Layout; Figure 2. STM32 L053 Discovery Board Hardware Block Diagram

Hardware layout UM1775
10/39 UM1775 Rev 4
6 Hardware layout
The STM32L053 Discovery board is designed around the STM32L053C8T6 microcontroller
in a 48-pin LQFP package.
Figure 2 illustrates the connections between the STM32L053C8T6 and its peripherals (ST-
LINK/V2-1, linear touch sensor, touchkeys, I
DD
current measurement, 2.13” E-paper
display, NFC connector for PLUG-CR95HF-B board, LEDs, push-buttons and an USB Mini-
B connector).
Figure 3 and Figure 4 help users to locate these features on the STM32L053 Discovery
board.
Figure 2. STM32L053 Discovery board hardware block diagram
Embedded
ST-LINK/V2-1
STM32L053C8T6
I/O I/O
RESET
USB ST-LINK
Mini-B
SWDHeader
LEDs
LD3, LD4
Linear
touch sensor
NFC
connector
B2
RESET
B1
USER
I
DD
current
measurement
I/O
Header
MSv39739V2
E-paper display
I/O
USB USER
Mini-B
