6000 COUNTS DIGITAL MULTIMETER
20
The meter has serial data output function. It can be connected with PC by USB interface, so the measured data can
be recorded, analyzed, processed and printed by PC. Before use this function, you need install the PC-Link software
and USB driver in your PC.
Press the Hz% key while turn on the meter, the meter enter PC-Link mode, the symbol “PC-LINK” will appear on LCD,
and the serial data output function is active.
PC-LINK SOFT OPERATING MANUAL
1. Make sure the two Install USB driver and Install software files in the attached CD successfully installed before
2. Keep the meter in “OFF” status, pressing the Hz% key while turn on the meter and the symbol “PC-LINK” will
appear on the LCD if the serial data output function is active. (To disable the auto power off function, hold down the
SELECT key and Hz% key while turning the meter on.)
NOTE: If we want to enable the serial data output function during measuring, we have to turn off the meter first,
then operate according to step2.
3. Connect the meter’s OPTICAL PORT and computer USB port with the USB line.
4. Run the PC-LINK software, click the SET menu. Select the System Set. Thenselect the proper COM port in the
Serial Port Select. As for the proper COM port, we can view it in the Device Manager by following these steps:
Right-click the My Computer icon on the Windows desktop, and then click Properties.
Click the Hardware tab and then click Device Manager.
Scroll through the list of installed devices till you locate the Ports (Com and LPT) entry. Click the plus (+)
beside this entry to view the installed ports, If no errors occur, the Sunplus USB to Serial COM Port (COM x) will
appear, COM x is just the proper port, here x is a specific number.
5. Select the default sampling rate or you can select other desired sampling rate.
6. Now press the Start in the PC-LINK SOFT to measure and view the synchronic data or graph in the software
7. To disable the serial data output function, switch the meter to OFF location first.
8 .More information about the PC-LINK SOFT, please refer to the Help topic including in the software or enter our
website：www.mastech.com.cn
