GNSS expansion board
Evaluate using X-CUBE-GNSS1 (1/2)
9
2
1
From X-CUBE-GNSS1 software
resource package drag and drop
GetPos_*.bin (in Binary folder) on
Nucleo drive
• Connect the STM32 Nucleo board and the X-NUCLEO-GNSS1A1 expansion board
• Connect the GPS/GLONASS antenna to the connector on the X-NUCLEO-
GNSS1A1 expansion board
• Connect the STM32 Nucleo board to your PC
