OWNER’S MANUAL
Shallow Well Jet Pumps/
Tank Systems
© 2001, Sta-Rite Industries, Inc. PRINTED IN U.S.A. S410 (Rev. 6/13/01)
293 Wright Street, Delavan, WI 53115
“HN” Series
Installation/Operation/Parts
For further operating, installation,
or maintenance assistance:
Call 1-262-728-9181

Table of Contents

Questions and Answers

  • E
    Elizabeth EatonJul 30, 2025
    How to troubleshoot STA-RITE HN Water Pump motor that will not run?
    • C
      Caroline SimpsonJul 31, 2025
      If the STA-RITE Water Pump motor won't run, ensure the disconnect switch is on. If that's not the problem, check for a blown fuse or tripped circuit breaker and replace or reset it. Other potential causes include a defective starting switch (disconnect power before replacing it), loose or incorrectly wired wires at the motor (disconnect power and tighten the wiring), or dirty pressure switch contacts (disconnect power and file the contacts). Also, the capacitor voltage may be hazardous, so discharge the capacitor or consult a qualified electrician.
  • J
    Jessica Frank MDAug 9, 2025
    Why STA-RITE HN delivers water but does not shut off?
    • T
      Trevor FaulknerAug 9, 2025
      If the STA-RITE Water Pump delivers water but doesn't shut off or cycles too frequently, disconnect power and adjust or replace the pressure switch. Close any open faucets. Clean the venturi, nozzle, or impeller if clogged. Drain the tank to the air volume control port if the standard pressure tank is waterlogged. Check all pipe connections for air leaks. Inspect foot valve connections and replace the foot valve if leaking. To address low air charge in a pre-charged tank, disconnect power, relieve pressure, and check air pressure at the valve stem. If it's less than the pressure switch cut-in setting (30-50 PSI), add air until it's 2 PSI less than the cut-in setting. Check the air valve for leaks and replace the core if needed.
  • H
    Harold HernandezAug 14, 2025
    Why STA-RITE HN Water Pump motor runs hot and overload kicks off?
    • J
      johnsondouglasAug 14, 2025
      If the STA-RITE Water Pump motor runs hot and the overload kicks off, refer to the wiring instructions to ensure the motor is wired correctly. Check with the power company if the voltage is too low. If the pump cycles too frequently, install heavier wiring if the wire size is too small and refer to the section on too frequent cycling.
  • M
    Michael BakerAug 19, 2025
    What to do if STA-RITE Water Pump does not deliver water to full capacity?
    • L
      Luis UnderwoodAug 20, 2025
      If the STA-RITE Water Pump does not deliver water to full capacity, a deep well jet will be needed if your well depth to water is more than 25 feet. If steel piping is corroded or limed, replace it with plastic pipe where possible, otherwise with new steel pipe. Use larger piping if the current piping is too small in size. Backflush the well point or sink a new point if the existing one is packed.
  • C
    Courtney HollandAug 25, 2025
    Why is there air spurting from faucets with my STA-RITE HN?
    • C
      Christian BeltranAug 25, 2025
      If you're experiencing air spurts from the faucets with your STA-RITE Water Pump, it may be picking up prime; when it has picked up prime, it should pump solid water with no air. Check the joints on the suction side of the pump for leaks using soapy water. If the well is gaseous, consult the factory about installing a sleeve in the well. If there is intermittent over-pumping of the well (water drawn down below the foot valve), lower the foot valve if possible, otherwise restrict pump discharge.
  • J
    Joseph ThomasNov 3, 2025
    What to do if STA-RITE HN Water Pump motor runs but no water is delivered?
    • E
      Evelyn JohnsonNov 3, 2025
      If your STA-RITE Water Pump runs but doesn't deliver water, in a new installation, re-prime according to instructions. Check all connections on the suction line, AVC, and ejector for air leaks using soapy water or shaving cream. Replace the foot valve or check valve if necessary. If the installation is already in use, check all connections on the suction line and shaft seal. Lower the suction line into the water and re-prime. If the water level in the well exceeds 25 feet, a deep well pump is needed. Also, clean the foot valve or strainer if plugged, as well as the ejector or impeller. Replace a stuck check valve or foot valve. Thaw pipes if they are frozen. Bury pipes below the frost line, heat the pit or pump house, and raise the foot valve and/or strainer above the bottom of the water s...

Summary

Safety

READ AND FOLLOW SAFETY INSTRUCTIONS!

Essential safety guidelines and symbols for pump operation.

ELECTRICAL SAFETY

Critical electrical safety precautions for pump installation and maintenance.

GENERAL SAFETY

General safety advice for pump operation, maintenance, and work area.

Installation

REPLACING AN OLD PUMP

Steps for removing an old pump and installing a new one.

WELL POINT (DRIVEN POINT) INSTALLATION

Detailed instructions for installing pumps with driven well points.

CASED WELL INSTALLATION, 2” OR LARGER CASING

Procedures for installing pumps in cased wells (2" or larger).

INSTALLATION FOR SURFACE WATER

Guidelines for installing shallow well jet pumps for surface water sources.

Discharge Pipe and Pressure Tank Connections

PRE-CHARGE TANK CONNECTION

How to connect a pump to a pre-charged pressure tank.

STANDARD TANK CONNECTION

Instructions for connecting pumps to standard pressure tanks.

Electrical

Motor wiring connections through Pressure Switch

Diagram and steps for connecting motor wiring to the pressure switch.

WIRING CONNECTIONS

General wiring guidelines, voltage conversion, and code compliance.

Connection Procedure

Step-by-step guide for electrical grounding and power supply connections.

Wiring Chart - Recommended Wire and Fuse Sizes

Chart detailing wire sizes and fuse ratings based on distance and pump model.

Preparing to Start the Pump

PRIMING

Crucial steps for priming the pump and piping before operation.

Nozzle Clean Out (Low Pressure)

Method for cleaning the pump nozzle using specific tools.

Troubleshooting

Repair Parts

LIMITED WARRANTY

STA-RITE HN series Specifications

General IconGeneral
SeriesHN
CategoryWater Pump
TypeCentrifugal
ApplicationResidential, Commercial
Maximum HeadVaries by model
Maximum CapacityUp to 300 GPM
Voltage115/230V
Motor TypeTEFC (Totally Enclosed Fan Cooled)
Housing MaterialCast Iron
Maximum Flow RateUp to 300 GPM
Motor Power0.5 - 5 HP
PhaseSingle
MaterialCast Iron
Seal TypeMechanical Seal
