STA-RITE MAX-E-GLAS IITM - Page 8

8
TABLE II - RECOMMENDED FUSING AND WIRING DATA – P4R, P4RA MODELS
Serv. to Motor - Dist. in Ft. (M)
Motor Branch Fuse Max Load Voltage/ 0-100' 101-200' 201-300'
HP Rating Amps* Amps Hz/Phase (0-30 M) (30-60 M) (60-90 M)
P4R Models:
13019.2 115/60/1 10(5.5) 8(8.4) 6(14)
115 9.6 230/60/1 14(2) 14(2) 12(3)
1-1/2 15 12.0 230/60/1 14(2) 14(2) 12(3)
215 11.2 230/60/1 14(2) 14(2) 12(3)
P4RA Models:
1 20/15 15.3/7.6 115/230/60/1 12/14(3/2) 8/14(8.4/2) 6/14(14/2)
1-1/2 30 19.2 115/60/1 10(5.5) 8(8.4) 6(14)
1-1/2 15 9.6 230/60/1 14(2) 14(2) 12(3)
1-3/4 15 12.0 230/60/1 14(2) 14(2) 12(3)
215 12.0 230/60/1 14(2) 14(2) 12(3)
2-1/2 15 11.2 230/60/1 14(2) 14(2) 12(3)
P4RA 2-Speed Models:
1-1/2 - 1/4 15 9.2/2.5 230/60/1 14(2) 14(2) 12(3)
2 - 1/3 15 10.2/3.7 230/60/1 14(2) 14(2) 12(3)
P4R62 Models:
3/4 15 3.8 200/60/3 14(2) 14(2) 14(2)
115 5.6 200/60/3 14(2) 14(2) 14(2)
1-1/2 15 6.6 200/60/3 14(2) 14(2) 14(2)
215 9.8 200/60/3 14(2) 14(2) 14(2)
P4R6 3-Phase Models:
3/4 15/15 3.6/1.8 230/460/60/3 14(2) 14(2) 14(2)
1 15/15 4.7/2.35 230/460/60/3 14(2) 14(2) 14(2)
1-1/2 15/15 5.8/2.9 230/460/60/3 14(2) 14(2) 14(2)
2 15/15 7.0/3.5 230/460/60/3 14(2) 14(2) 14(2)
2-1/2 15/15 9.7/4.9 230/460/60/3 14(2) 14(2) 12(3)/14(2)
3 15/15 11.5/5.8 230/460/60/3 14(2) 14(2) 12(3)/14(2)
* Time delay fuses are recommended instead of standard fuses in any motor circuit.
Wire
Size
AWG
(mm
2
)
}
Wire
Size
AWG
(mm
2
)
}
Wire
Size
AWG
(mm
2
)
}
Wire Size
AWG (mm
2
)
}
Wire
Size
AWG
(mm
2
)
}
TABLE I - RECOMMENDED FUSING AND WIRING DATA – P4E, P4EA MODELS
Serv. to Motor - Dist. in Ft. (M)
Motor Branch Fuse Max Load Voltage/ 0-100' 101-200' 201-300'
HP Rating Amps* Amps Hz/Phase (0-30 M) (30-60 M) (60-90 M)
P4E Models:
3/4 20 13.8 115/60/1 12(3) 10(5.5) 8(8.4)
125 16.0 115/60/1 12(3) 8(8.4) 6(14)
115 8.0 230/60/1 14(2) 14(2) 14(2)
1-1/2 15 10.4 230/60/1 14(2) 12(3) 12(3)
215 11.2 230/60/1 14(2) 12(3) 12(3)
215 1.5 575/60/3 14(2) 14(2) 14(2)
315 3.4 575/60/3 14(2) 14(2) 14(2)
325 15.8 230/60/1 12(3) 12(3) 10(5.5)
P4EA Models:
12013.8 115/60/1 12(3) 10(5.5) 8(8.4)
1-1/2 25 16.0 115/60/1 12(3) 8(8.4) 6(14)
115 6.9 230/60/1 14(2) 14(2) 14(2)
1-1/2 15 8.0 230/60/1 14(2) 14(2) 12(3)
1-3/4 15 10.4 230/60/1 14(2) 12(3) 12(3)
215 10.4 230/60/1 14(2) 12(3) 12(3)
2-1/2 15 11.2 230/60/1 14(2) 12(3) 12(3)
P4E62 Models:
3/4 20 13.4 100/60/1 14(2) 12(3) 8(8.4)
3/4 15 6.7 200/60/1 14(2) 14(2) 14(2)
115 7.4 200/60/1 14(2) 14(2) 12(3)
1-1/2 15 10.5 200/60/1 14(2) 12(3) 12(3)
220 14.2 200/60/1 12(3) 12(3) 10(5.5)
325 17.6 200/60/1 10(5.5) 10(5.5) 10(5.5)
* Time delay fuses are recommended instead of standard fuses in any motor circuit.
Wire
Size
AWG
(mm
2
)
}
Wire
Size
AWG
(mm
2
)
}
Wire
Size
AWG
(mm
2
)
}
