STACYC 16EDRIVE - Component Replacement Procedures; Fuse and Chain Replacement

P a g e | 22P a g e |
Fuse located inside
of down tube
◀
2. Determine if brake cable has too much
slack or brake hub is dragging on the brake
pad:
a. Loosen brake hub barrel adjuster.
b. Adjust brake hub adjuster in or out
unl desired brake adjustment is at-
tained.
c. Lock brake hub barrel adjuster.
d. Perform nal adjustment of tension in
brake cable with brake lever barrel adjuster.
e. Repeat “Test Brake” secon above.
Replace Fuse:
WARNING: Motor and Electronic Speed Controller (ESC) can be very hot and cause
burns. It is crical that the cycle is allowed to cool prior to accessing motor and ESC.
WARNING: To prevent shock, follow the instrucons and do not skip any steps.
1. Place power switch in “OFF” posion.
2. Remove baery from cycle.
3. Remove foot plaorm.
4. Remove right side panel, allow motor and Electronic Speed Controller adequate
me to cool before you proceed.
5. Locate fuse. Remove the fuse from socket. Verify that replacement fuse is the
specied amperage. Replace fuse.
6. Re-Install right side panel.
7. Install the foot plaorm.
Chain Tensioner
Bolt to secure brake hub
◀
◀
Replace Chain:
