Note: Chain may be greasy and dirty.
Turn power switch to “OFF” posion, remove baery, allow cycle to cool before beginning
repair or maintenance:
1. Ensure the power switch is “OFF”.
2. Ensure the baery is removed and cycle has had adequate me to cool. (up to 30 minutes)
3. Secure the cycle for repair or maintenance.
4. Exercise cauon around exposed parts.
5. Remove foot rest.
6. Remove right side panel.
7. Rotate rear wheel unl master chain link is near motor sprocket.
8. Loosen both rear axle nuts, bolt securing brake hub and loosen chain tensioner.
9. Push wheel forward to loosen chain.
10. Remove master chain link, then chain.
11. Install replacement chain, re-aach master link.
12. Tension chain by pulling rear wheel outward with aid of chain tensioner, aligning the re
straight forward.
13. Tighten rear axle nuts, bolt securing brake hub and snug chain tensioner.
14. Install right side panel.
Replace Front Tire and/or Tube:
1. Loosen front axle nuts and axle keeper tabs.
2. Remove wheel.
3. Deate tube and remove re from wheel.
4. Install new re and/or tube onto sidewall.
5. Inate to pressure recommended on sidewall.
6. Install front wheel and ghten from axle nuts, posioning axle keeper tabs into lower hole
in fork blade.
Replace Rear Tire and/or Tube:
1. Remove foot rest.
2. Remove right side panel.
3. Loosen rear anchor bolt of brake assembly to release brake cable.
4. Remove brake assembly mount bolt.
5. Loosen rear axle nuts and remove chain tensioner assembly.
6. Push rear wheel forward and remove chain from motor sprocket.
7. Remove rear wheel.
8. Deate tube and remove re from wheel.
9. Install new re and/or tube onto wheel.
10. Inate to pressure recommended on sidewall.
11. Tension chain by pulling rear wheel outward with aid of chain tensioner, aligning the re
straight forward.
12. Tighten rear axle nuts, bolt securing brake hub and snug chain tensioner.
13. Tighten rear anchor bolt of brake assembly to capture brake cable.
14. Install right side panel.
Seat Height Adjustment:
1. Release the seat height adjustment clamp and extend the seat post unl the desired seat
