STACYC Stability Cycle - Page 3

P a g e | 4P a g e | 4 DOC 001 REV A DOC 001 REV A P a g e | 5
10. Headset
11. Side panels
12. Chain guard
13. Chain
14. Seat
15. Seat clamp
16. Frame
17. Baery
18. Rear axle nuts
19. Chain tensioner
20. Drum brake assembly
21. Rear wheel
22. Drive sprocket
23. Drive motor
24. Electric Speed Controller, ESC
25. Fuse(*inside down tube)
1. Handlebar
2. Handlebar grip
3. Brake lever
4. Throle
5. Front fork
6. Stem
7. Front wheel
8. Foot rest
9. Front axle nuts
13 23
22
24
25*
3
4
5
7
8
9
10
6
11
12
14
15
16
17
18
19
20
21
1
2
