6 Transport and storage
• Transport and store the device only in the original packaging.
• Transport the device only using appropriate means of transport, e.g. crane or forklift.
• Store the device in a dry place (no condensation) and vibration-free.
• Do not drop the device.
7 Mounting and installation
7.1 Dimensions / fastening dimensions
Dimensional Drawings (All Dimensions in mm [inches]) - Subject to Alterations
16498E00
Enclosure Series 8264
J/2
I/2
J
I
A
D
C
E
M12
B
