167225 / 8264605300
2015-02-03·BA00·III·en·04
Mounting and installation
15
Control and Distribution Panel in
flameproof enclosure
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
7.2 Mounting / dismounting, operating position
This device is suitable for outdoor and indoor use.
• Provide a protective roof or wall if enclosure and explosion protected electrical
equipment is used outdoors.
• For the operating position refer to the attached documentation.
• Mount the component on a flat surface.
• Fasten the device to the mounting holes, provided for this purpose, using suitable
screws and accessories (see dimensional drawings).
• Place the Ex d enclosure on the mounting rail and connect it using M12 screws
(observe weight, see chapter "Technical data")
Ex e terminal compartment.
To prevent condensation in the enclosure, we recommend using a breather,
type 8162 by R. STAHL Schaltgeräte GmbH.
By using a breather and depending on its mounting position, the degree of
protection acc. to IEC 60529 is reduced. If mounted lateral, the degree of
protection is IP64, if opening of breather is installed downwards, it is IP56.
DANGER
Explosion hazard due to unauthorized cable entries!
Non-compliance results in severe or fatal injuries.
• Use only cable entries approved for the required type of protection.
• When selecting cable glands, observe the thread type and thread size
in the equipment documentation.
DANGER
Explosion hazard due to open holes or unused cable glands!
Non-compliance results in severe or fatal injuries.
• Always close drilled holes and unused cable glands using approved
stopping plugs or plugs.
• When selecting cable glands, observe the thread type and thread size
in the equipment documentation.
WARNING
Mechanical overload of the device!
Non-compliance can result in severe or fatal injuries and material damage.
• Install protective wire grid.
• Install the device only in locations with little vehicle and pedestrian
traffic.
