Stahl 8264 - Page 40

Mounting and installation
14
167225 / 8264605300
2015-02-03·BA00·III·en·04
Control and Distribution Panel in
flameproof enclosure
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Aluminium:
Empty enclo-
sure Type
A B C I D E F J I / 2 J / 2
8264/-114-3 235
[9.25]
235
[9.25]
260
[10.24]
205
[8.07]
8.5
[0.33]
12.5
[0.47]
2
[0.08]
205
[8.07]
8264/-214-3 360
[14.17]
235
[9.25]
260
[10.24]
205
[8.07]
8.5
[0.33]
12.5
[0.47]
2
[0.08]
330
[12.99]
8264/-224-3 360
[14.17]
360
[14.17]
260
[10.24]
330
[12.99]
8.5
[0.33]
12.5
[0.47]
2
[0.08]
330
[12.99]
8264/-225-3 360
[14.17]
360
[14.17]
330
[12.99]
330
[12.99]
8.5
[0.33]
12.5
[0.47]
2
[0.08]
330
[12.99]
8264/-324-3 480
[18.9]
360
[14.17]
260
[10.24]
330
[12.99]
8.5
[0.33]
12.5
[0.47]
2
[0.08]
450
[17.72]
8264/-325-3 480
[18.9]
360
[14.17]
330
[12.99]
330
[12.99]
8.5
[0.33]
12.5
[0.47]
2
[0.08]
450
[17.72]
8264/-334-3 480
[18.9]
480
[18.9]
260
[10.24]
450
[17.72]
8.5
[0.33]
12.5
[0.47]
2
[0.08]
450
[17.72]
8264/-335-3 480
[18.9]
480
[18.9]
330
[12.99]
450
[17.72]
8.5
[0.33]
12.5
[0.47]
2
[0.08]
450
[17.72]
8264/-934-3 730
[28.74]
480
[18.9]
260
[10.24]
450
[17.72]
18
[0.71]
22
[0.87]
2
[0.08]
700
[27.56]
8264/-935-3 730
[28.74]
480
[18.9]
330
[12.99]
450
[17.72]
18
[0.71]
22
[0.87]
2
[0.08]
700
[27.56]
8264/-995-3 730
[28,74]
730
[28.74]
330
[12.99]
700
[27.56]
18
[0.71]
22
[0.87]
2
[0.08]
700
[27.56]
8264/-996-3 730
[28.74]
730
[28.74]
465
[18.31]
700
[27.56]
18
[0.71]
22
[0.87]
16
[0.63]
700
[27.56]
350
[13.78]
350
[13.78]
8264/-997-3 730
[28.74]
730
[28.74]
570
[22.44]
700
[27.56]
18
[0.71]
22
[0.87]
16
[0.63]
700
[27.56]
350
[13.78]
350
[13.78]
8264/-998-3 730
[28.74]
730
[28.74]
480
[18.9]
700
[27.56]
18
[0.71]
22
[0.87]
16
[0.63]
700
[27.56]
350
[13.78]
350
[13.78]
8264/-999-3 730
[28.74]
730
[28.74]
585
[23.03]
700
[27.56]
18
[0.71]
22
[0.87]
16
[0.63]
700
[27.56]
350
[13.78]
350
[13.78]
