Connection terminals
Tighten the screws of the connection terminals in accordance with the specified
tightening torque, see table.
Captive screw
Stainless steel:
Empty enclosure Type Tightening torque
[Nm]
Captive screw
8264/-112-2...1
20
Cheese-head screws
M10x40 A4-70 similar to ISO
4762
8264/-212-2...1
8264/-222-2...1
8264/-223-2...1
8264/-323-2...1
8264/-333-2...1
8264/-933-2...1
32
Cheese-head screws
M12x40 A4-80 similar to ISO
4762
8264/-993-2...1
8264/-998-2...1
43
Cheese-head screws
M14x60 A4-80 similar to ISO
4762
8264/-999-2...1
Aluminium:
Empty enclosure Type Tightening torque
[Nm]
Captive screw
8264/-114-3...1
20
Cheese-head screws
M10x40 A4-70 similar to ISO
4762
8264/-214-3...1
8264/-224-3...1
8264/-225-3...1
8264/-324-3...1
8264/-325-3...1
8264/-334-3...1
8264/-335-3...1
8264/-934-3...1
8264/-935-3...1
8264/-995-3...1
8264/-998-3...1
43
Cheese-head screws
M14x60 A4-80 similar to ISO
4762
8264/-999-3...1
Screw dimension M3 M4 M5 M6 M8 M10
Tightening torque [Nm] 0.8 2.0 3.5 5.0 10.0 17.0
