Stamina 1405 - Step 4: Rear Stand Attachment

ASSEMBLY INSTRUCTIONS
10
STEP 4
Attach the REAR STAND(2) to the RAIL(1) with FLAT HEAD BOLTS(M8x1.25x8mm)(74) and FLAT HEAD
BOLTS(M8x1.25x15mm)(75).
STEP 5
Attach the RAIL CAP(46) to the REAR STAND(2) with ROUND HEAD SCREWS(M5x10mm)(68).
STEP 6
Remove the LOCKING KNOB(44) from the SUPPORT FRAME(4). Remove the PULL PIN(43) from the
RAIL(1). Unfold the FAN ASSEMBLY by swinging the SUPPORT FRAME(4) toward the front.
