ASSEMBLY INSTRUCTIONS
11
STEP 7
Lock the SUPPORT FRAME(4) on the RAIL(1) with the LOCKING KNOB(44). Insert the PULL PIN(43)
into the hole on the RAIL(1) for storage.
STEP 8
Install two AA batteries into the METER(35), the batteries are not included. See page 12 for detailed battery
installation instructions. Connect the UPPER CONNECTION WIRE(33) and LOWER CONNECTION
WIRE(37) to the METER(35). Press the METER(35) into the CONSOLE(36).
