ASSEMBLY INSTRUCTIONS
7
STEP 1
Attach the REAR STABILIZER(2) to the MAIN FRAME(1) with CARRIAGE BOLTS(M10x1.5x43mm)
(42) and NYLOCK NUTS(M10x1.5)(51).
STEP 2
Attach the BASE BOARD(37) to the MAIN FRAME(1) with the STANDS(40) and BUTTON HEAD
BOLTS(M8x1.25x16mm)(59).
STEP 3
Attach the LEFT PEDAL CAP(33) to the LEFT PEDAL ARM(3) with BUTTON HEAD BOLTS
(M8x1.25x20mm)(45). Repeat on the other side.
NOTE: The LEFT and RIGHT PEDAL CAPS(33, 34) have a raised lip on three sides. Attach the LEFT
and RIGHT PEDAL CAPS(33, 34) to the LEFT and RIGHT PEDAL ARMS(3, 4) so that the side
without the raised lip is on the outside.
Placeallpartsfromtheboxinaclearedareaandpositionthemontheoorinfrontofyou.Remove
all packing materials from your area and place them back into the box. Do not dispose of the packing
materials until assembly is completed. Read each step carefully before beginning. If you are missing
apart,pleasegotostaminaproducts.comtotheServicessectionandorderthepartneeded,e-mail
usatcustomerservice@staminaproducts.com,orcallustollfreeat1-800-375-7520(intheU.S.).Our
CustomerServiceStaffisavailabletoassistyoufrom7:30A.M.to5:00P.M.(CentralTime)Monday
throughThursdayand8:00A.M.to3:00P.M.(CentralTime)onFriday.
