MAIN Unit

PCB with Components CB3497001

Printed Circuit Board FR014690C 1

FR014690D 2-

C 1001 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A E4

C 1002 CHIP TA.CAP. 4.7uF 10V TEMSVA1A475M-8R K78100022 1- A E4

C 1003 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A E3

C 1004 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A D3

C 1005 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A D3

C 1006 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A D3

C 1007 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A C3

C 1008 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A C3

C 1009 AL.ELECTRO.CAP. 47uF 16V EEE1CA470SP K48120005 1- A B3

C 1010 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C3

C 1011 AL.ELECTRO.CAP. 47uF 16V EEE1CA470SP K48120005 1- A C4

C 1012 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A A3

C 1013 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C3

C 1014 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A C3

C 1015 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A A3

C 1016 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A B3

C 1017 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 1018 CHIP TA.CAP. 1uF 35V TEMSVA1V105M-8R K78160032 1- A B3

C 1019 AL.ELECTRO.CAP. 2200uF 25V RE3-25V222MI6# K40149055 1- A D1

C 1020 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A A2

C 1021 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A A2

C 1022 AL.ELECTRO.CAP. 47uF 16V EEE1CA470SP K48120005 1- A A2

C 1023 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A A2

C 1024 CHIP TA.CAP. 47uF 16V TEMSVC1C476M12R K78120057 1- A A1

C 1025 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A A1

C 1026 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A A1

C 1027 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A A1

C 1028 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A A1

C 1029 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A A1

C 1030 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A1

C 1031 CHIP TA.CAP. 1uF 35V TEMSVA1V105M-8R K78160032 1- A B1

C 1032 AL.ELECTRO.CAP. 47uF 35V EEE1VA470WP K48160005 1- A B1

C 1033 AL.ELECTRO.CAP. 220uF 25V EKMQ250ELL221MF11D K40149071 1- A C1

C 1034 CHIP CAP. 0.15uF 25V B GRM40B154K25PT K22140823 1- A C2

C 1035 CHIP CAP. 0.15uF 25V B GRM40B154K25PT K22140823 1- A C2

C 1036 AL.ELECTRO.CAP. 220uF 25V EKMQ250ELL221MF11D K40149071 1- A D1

C 1037 AL.ELECTRO.CAP. 220uF 25V EKMQ250ELL221MF11D K40149071 1- A C1

C 1038 CHIP CAP. 0.15uF 25V B GRM40B154K25PT K22140823 1- A B2

C 1039 CHIP CAP. 0.15uF 25V B GRM40B154K25PT K22140823 1- A A2

C 1040 AL.ELECTRO.CAP. 220uF 25V EKMQ250ELL221MF11D K40149071 1- A C1

C 1041 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A C4

C 1042 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A C4

C 1043 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A A3

C 1044 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A F4

C 1045 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A F4

C 1046 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A F4

C 1047 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A F3

C 1048 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A G3

C 1049 CHIP TA.CAP. 1uF 35V TEMSVA1V105M-8R K78160032 1- A D3

C 1050 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A F3

C 1051 CHIP TA.CAP. 1uF 35V TEMSVA1V105M-8R K78160032 1- A F2

C 1052 CHIP TA.CAP. 1uF 35V TEMSVA1V105M-8R K78160032 1- A F2

C 1053 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A G4

C 1054 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A G4

C 1055 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G4

C 1056 AL.ELECTRO.CAP. 47uF 16V EEE1CA470SP K48120005 1- A G4

C 1057 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A G2

C 1058 AL.ELECTRO.CAP. 47uF 16V EEE1CA470SP K48120005 1- A G3

C 1059 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174813 1- A G2

C 1060 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A G2

C 1061 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A G1

C 1062 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G2

C 1063 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A G2

C 1064 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G1

C 1065 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- A G1

C 1066 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- A F1

C 1067 CHIP TA.CAP. 4.7uF 25V TEMSVB21E475M-8R K78140019 1- A G1

C 1068 AL.ELECTRO.CAP. 100uF 25V EMVA250ADA101MF80G K48140016 1- A F1

C 1069 AL.ELECTRO.CAP. 220uF 25V EKMQ250ELL221MF11D K40149071 1- A E1

C 1070 AL.ELECTRO.CAP. 220uF 25V EKMQ250ELL221MF11D K40149071 1- A F1

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

Parts List
