16
MAIN Unit
C 1071 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A E3
C 1072 AL.ELECTRO.CAP. 100uF 25V EMVA250ADA101MF80G K48140016 1- A E3
C 1073 AL.ELECTRO.CAP. 100uF 25V EMVA250ADA101MF80G K48140016 1- A E1
C 1074 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E4
C 1075 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A E3
C 1076 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A A3
C 1077 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A A1
C 1078 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A C4
C 1079 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A C3
C 1080 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A B2
C 1081 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A G1
C 1082 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174813 1 A G1
C 1082 CHIP CAP. 560pF 50V B GRM188B11H561KA01D K22174806 2- A G1
C 1083 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A E1
C 1084 AL.ELECTRO.CAP. 2200uF 25V RE3-25V222MI6# K40149055 1- A E2
C 1085 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G1
C 1086 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A F2
C 1087 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A E2
C 1088 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F1
C 1089 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A E3
C 1090 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A E1
C 1091 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- A G1
C 1092 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- A G1
C 1093 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A G1
C 1101 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A E3
C 1102 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A E3
C 1103 CHIP CAP. 0.1uF 25V F GRM39F104Z25PT K22145001 1- A D2
C 1104 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A D2
C 1105 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A D2
C 1106 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A F3
C 1107 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G1
C 1108 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F1
C 1113 TANTALUM CAP. 1uF 16V SS2-1C105-T2 K76120024 1 A E4
C 1113 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 2- A E4
C 1114 TANTALUM CAP. 1uF 16V SS2-1C105-T2 K76120024 1 A G2
C 1114 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 2- A G2
D 1001 DIODE 1SS307(TE85L.F) G2071118 1- A B3
D 1002 DIODE 1SS307(TE85L.F) G2071118 1- A A2
D 1003 DIODE 1SS307(TE85L.F) G2071118 1- A G2
D 1004 DIODE D1F20-5063 G2070474 1- A C2
D 1005 DIODE D1F20-5063 G2070474 1- A B2
D 1006 DIODE D1F20-5063 G2070474 1- A F2
D 1007 DIODE D1F20-5063 G2070474 1- A E2
D 1008 DIODE 1N5402 G2090778 1- A E1
D 1009 DIODE DAN202U T106 G2070162 2- A F3
J 1001 CONNECTOR B2B-PH-K-S P0090396 1- B c4
J 1002 CONNECTOR 24FLT-SM1-TB P1091128 1- A D4
J 1003 CONNECTOR B3B-PH-K-S P0090397 1- B f3
J 1004 CONNECTOR B3B-PH-K-S P0090397 1- B b4
J 1005 CONNECTOR B3B-PH-K-S P0090397 1- B a4
J 1006 CONNECTOR B2B-PH-K-S P0090396 1- B c1
J 1008 CONNECTOR B2B-PH-K-S P0090396 1- B b1
J 1011 CONNECTOR B2B-PH-K-S P0090396 1- B e4
J 1012 CONNECTOR B6B-PH-K-S P0090400 1- B b1
J 1021 TERMINAL 26004 Q5000167 1- B e2
J 1022 TERMINAL 26004 Q5000167 1- B f2
J 1023 TERMINAL 26004 Q5000167 1- B f1
J 1024 TERMINAL 26004 Q5000167 1- B f1
L 1001 AFC 150uH 7313NA-151K L2190061 1- A E1
Q 1001 TRANSISTOR DTC124EE TL G3070109 1- A C3
Q 1002 TRANSISTOR DTC124EE TL G3070109 1- A C3
Q 1003 TRANSISTOR DTC124EE TL G3070109 1- A C4
Q 1004 TRANSISTOR DTC124EE TL G3070109 1- A C4
Q 1005 IC TC4W66FU(TE12L.F) G1091676 1- A G1
Q 1007 TRANSISTOR DTC124EE TL G3070109 1- A F2
Q 1008 TRANSISTOR DTC124EE TL G3070109 1- A E2
Q 1011 IC TC7W53FU(TE12L_F) G1094158 1- A D3
Q 1012 IC TC4W66FU(TE12L.F) G1091676 1- A D3
Q 1013 IC LA3210B-E G1094267 1- A C3
Q 1014 IC LA3210B-E G1094267 1- A A2
Q 1015 IC TA8231LQ G1094265 1- A C1
Q 1016 IC TC7W53FU(TE12L_F) G1094158 1- A F3
Q 1017 IC TC7W53FU(TE12L_F) G1094158 1- A F3
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.
LOT
SIDE
LAY ADR
Parts List
To Next Page
