VR-B-Unit
31
Parts Layout
Side B
Side A
Circuit Diagram
PCB with Components CB3643001
Printed Circuit Board FR015180B 1-
JP6201 WIRE ASSY AM020X ICVR T9207323 1- A
VR6201 POT. RK0971110 20KB J60800261 1- A
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.
LOT
SIDE
LAY ADR
