Standard Horizon VLH-3000 Service Manual

22
CNTL Unit
Parts List
D 2030 LED UR1111C G2071110 1- A C3
D 2031 LED UR1111C G2071110 1- A C3
D 2032 LED UG1111C G2071112 1- A C3
D 2033 LED UR1111C G2071110 1- A C4
D 2034 LED UR1111C G2071110 1- A C4
D 2035 LED UG1111C G2071112 1- A C4
D 2036 LED UR1111C G2071110 1- A C5
D 2037 LED UR1111C G2071110 1- A C5
D 2038 LED UG1111C G2071112 1- A C5
D 2039 LED UR1111C G2071110 1- A B1
D 2040 LED UR1111C G2071110 1- A B2
D 2041 LED UR1111C G2071110 1- A C1
D 2042 LED UR1111C G2071110 1- A C2
D 2043 LED UG1111C G2071112 1- A D1
D 2044 LED UG1111C G2071112 1- A D2
D 2045 LED UG1111C G2071112 1- A E1
D 2046 LED UG1111C G2071112 1- A E2
D 2047 LED UY1111C G2071114 1- A F1
D 2048 LED UY1111C G2071114 1- A F2
J 2001 CONNECTOR B3B-PH-SM3-TBT P0091369 1- B f4
J 2002 CONNECTOR B9B-ZR-SM4-TFT(LF)(SN) P0091374 1- B b1
J 2003 CONNECTOR 24FLT-SM1-TB P1091128 1- B e1
Q 2001 TRANSISTOR DTA144EE TL G3070074 1- B c2
Q 2002 TRANSISTOR DTC124EE TL G3070109 1- B c1
Q 2003 TRANSISTOR DTC124EE TL G3070109 1- B e2
Q 2004 TRANSISTOR DTC124EE TL G3070109 1- B e2
Q 2005 TRANSISTOR DTC124EE TL G3070109 1- B e3
Q 2006 TRANSISTOR DTC124EE TL G3070109 1- B e3
Q 2007 TRANSISTOR DTC124EE TL G3070109 1- B d3
Q 2008 TRANSISTOR DTC124EE TL G3070109 1- B e3
Q 2009 TRANSISTOR DTC124EE TL G3070109 1- B e4
Q 2010 TRANSISTOR DTC124EE TL G3070109 1- B e4
Q 2011 TRANSISTOR DTC124EE TL G3070109 1- B e4
Q 2012 TRANSISTOR DTC124EE TL G3070109 1- B e5
Q 2013 TRANSISTOR DTC124EE TL G3070109 1- B e5
Q 2014 TRANSISTOR DTC124EE TL G3070109 1- B e5
Q 2015 TRANSISTOR DTC124EE TL G3070109 1- B d3
Q 2016 TRANSISTOR DTC124EE TL G3070109 1- B d3
Q 2017 TRANSISTOR DTC124EE TL G3070109 1- B d3
Q 2018 TRANSISTOR DTC124EE TL G3070109 1- B d4
Q 2019 TRANSISTOR DTC124EE TL G3070109 1- B d4
Q 2020 TRANSISTOR DTC124EE TL G3070109 1- B d3
Q 2021 TRANSISTOR DTC124EE TL G3070109 1- B d4
Q 2022 TRANSISTOR DTC124EE TL G3070109 1- B d4
Q 2023 TRANSISTOR DTC124EE TL G3070109 1- B d4
Q 2024 TRANSISTOR DTC124EE TL G3070109 1- B d5
Q 2025 TRANSISTOR DTC124EE TL G3070109 1- B d5
Q 2026 TRANSISTOR DTC124EE TL G3070109 1- B d5
Q 2027 TRANSISTOR DTC124EE TL G3070109 1- B a2
Q 2028 TRANSISTOR DTC124EE TL G3070109 1- B a2
Q 2029 TRANSISTOR DTC124EE TL G3070109 1- B a2
Q 2030 TRANSISTOR DTC124EE TL G3070109 1- B a2
Q 2031 TRANSISTOR DTC124EE TL G3070109 1- B a2
Q 2041 IC HD64F36064GFPV Ú 1- B b3
Q 2042 IC BR24L01AFJ-W G1094332 1- B b2
Q 2043 IC NJM78L05UA-TE1 G1091325 1- B f3
Q 2044 IC NJM78M09DL1A G1094262 1- B c2
Q 2045 IC PST597CNR G1092589 1- B b4
R 2001 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B a1
R 2002 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B b1
R 2003 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B b1
R 2004 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B b1
R 2005 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B b1
R 2006 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B b1
R 2007 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B e4
R 2008 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B e4
R 2009 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e4
R 2010 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B e4
R 2011 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b1
R 2012 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b1
R 2014 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b1
R 2015 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b1
R 2016 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B d2
Ú
:
Please contact Vertex Standard
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
