CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a 10°
TD, 90° Ambient
Ref.
Base
Size
(See pp.
39-41) H.P.
Connections
MCA Voltage -20 -10 0 Liquid Suction
BCLX030DC 2DF3-0300-TFC 2DF3-0300-TFC 11750 15865 21029 R-22 C 3 5/8 1 3/8 38 208-230/60/3
BCLX0400G 2DL3-0400-TFD 2DL3-0400-TFD 11200 15530 20580 R-22 C 4 5/8 1 3/8 22 380-420/50/3
BCLX040DC 2DL3-0400-TFC 2DL3-0400-TFC 13440 18636 24696 R-22 C 4 5/8 1 3/8 44 208-230/60/3
BCLX040DG 2DL3-0400-TFD 2DL3-0400-TFD 11200 15530 20580 R-22 C 4 5/8 1 3/8 22 380-420/50/3
BCLX060DC 2DB3-0600-TFC 2DB3-0600-TFC 15998 21912 28600 R-22 C 6 5/8 1 3/8 46 208-230/60/3
BCLX075DC 3DB3-0750-TFC 3DB3-0750-TFC 25581 33767 43526 R-22 D 7.5 7/8 1 3/8 55 208-230/60/3
BCLX075DG 3DB3-0750-TFD 3DB3-0750-TFD 25581 33767 43526 R-22 D 7.5 7/8 1 3/8 38 380/420/50/3
BCLX090DC 3DF3-0900-TFC 3DF3-0900-TFC 30168 40763 53201 R-22 E 9 7/8 1 3/8 68 208-230/60/3
BCLX100DC 3DS3A1000-TFC 3DS3-100E-TFC 32616 43857 56745 R-22 E 10 7/8 1 3/8 71 208-230/60/3
BCLX150DC 4DL3-1500-TSK 4DL3-1500-TSK 46221 61906 79918 R-22 F 15 7/8 1 5/8 90 208-230/60/3
BCLZ0050B EJAL-A050-CAV KAN2-0050-CAV 1490 2030 2640 R-404A A .5 3/8 5/8 14 208-230/60/1
BCLZ0050C EJAL-A050-TAC KAN1-0050-TAC 1490 2030 2640 R-404A A .5 3/8 5/8 14 208-230/60/3
BCLZ0070B EJAL-A075-CAV KAMB-007E-CAV 2490 3370 4430 R-404A A .75 3/8 5/8 13 208-230/60/1
BCLZ0070C EJAL-A075-TAC KAMA-007E-TAC 2490 3370 4430 R-404A A .75 3/8 5/8 13 208-230/60/3
BCLZ0100B EJAL-A100-CAV KAJB-010E-CAV 3310 4400 5630 R-404A A 1 3/8 5/8 14 208-230/60/1
BCLZ0100C EJAL-A100-TAC KAJA-011E-TAC 3310 4400 5630 R-404A A 1 3/8 5/8 14 208-230/60/3
BCLZ0150B KALB-015E-CAV KALB-015E-CAV 5112 6659 8313 R-404A B 1.5 3/8 7/8 18 208-230/60/1
BCLZ0150C KALA-016E-TAC KALA-016E-TAC 5112 6659 8313 R-404A B 1.5 3/8 7/8 14 208-230/60/3
BCLZ0150CC KALA-016E-TAC KALA-016E-TAC 5112 6659 8313 R-404A B 1.5 3/8 7/8 14 208-230/60/3
BCLZ0150E KALA-016E-TAD KALA-016E-TAD 5112 6659 8313 R-404A C 1.5 3/8 7/8 14 460/60/3
BCLZ015XB KALB-015E-CAV KALB-015E-CAV 5112 6659 8313 R-404A B 1.5 3/8 7/8 18 208-230/60/1
BCLZ0170B KATB-015E-CAV KATB-015E-CAV 6043 7857 0 R-404A B 1.7 3/8 7/8 18 208-230/60/1
BCLZ0170C KATA-015E-TAC KATA-015E-TAC 6043 7857 0 R-404A B 1.7 3/8 7/8 14 208-230/60/3
BCLZ017FB KATB-015E-CAV KATB-015E-CAV 6043 7857 0 R-404A B 1.7 3/8 7/8 18 208-230/60/1
BCLZ0200B EAVB-021E-CAV EAVB-021E-CAV 6489 8448 10773 R-404A B 2 3/8 7/8 26 208-230/60/1
BCLZ0200C EAVA-021E-TAC EAVA-021E-TAC 6489 8448 10773 R-404A B 2 3/8 7/8 20 208-230/60/3
BCLZ0200E EAVA-021E-TAD EAVA-021E-TAD 6489 8448 10773 R-404A C 2 3/8 7/8 14 460/60/3
BCLZ020FB EAVB-021E-CAV EAVB-021E-CAV 6489 8448 10773 R-404A B 2 3/8 7/8 26 208-230/60/1
BCLZ020WC WJWL-0200-TAC EWVA-021E-TAC 6550 9150 12300 R-404A B 2 3/8 7/8 20 208-230/60/3
BCLZ020XC EAVA-021E-TAC EAVA-021E-TAC 6489 8448 10773 R-404A B 2 3/8 7/8 20 208-230/60/3
BCLZ020YC EAVA-021E-TAC EAVA-021E-TAC 6489 8448 10773 R-404A B 2 3/8 7/8 20 208-230/60/3
BCLZ0250B 3ABB-032E-CAB 3ABB-032E-CAB 7430 10472 13767 R-404A C 2.5 5/8 1 1/8 20 230/60/1
BCLZ0250C 3ABA-031E-TAC 3ABA-031E-TAC 7430 10472 13767 R-404A C 2.5 5/8 1 1/8 21 208-230/60/3
BCLZ025VCC 3ABA-031E-TAC 3ABA-031E-TAC 7430 10472 13767 R-404A C 2.5 5/8 1 1/8 21 208-230/60/3
BCLZ0280B LALB-032E-CAB LALB-032E-CAB 11560 15529 20084 R-404A C 3 5/8 1 1/8 32 230/60/1
BCLZ0280C LALA-032E-TAC LALA-032E-TAC 11560 15529 20084 R-404A C 3 5/8 1 1/8 32 208-230/60/3
BCLZ0280E LALA-032E-TAD LALA-032E-TAD 11560 15529 20084 R-404A C 3 5/8 1 1/8 20 460/60/3
BCLZ0280F LALA-032E-TAC LALA-032E-TAC 9630 12940 16730 R-404A C 3 5/8 1 1/8 32 200-220/50/3
BCLZ0280G LALA-032E-TAD LALA-032E-TAD 9630 12940 16730 R-404A C 3 5/8 1 1/8 20 380-400/50/3
BCLZ028UC LALA-032E-TAC LALA-032E-TAC 11560 15529 20084 R-404A C 3 5/8 1 1/8 32 208-230/60/3
BCLZ028UCW WJWL-0300-TFC NRD1-0302E-TFC 11200 15120 20400 R-404A C 3 1/2 1 1/8 32 208-230/60/3
BCLZ028UE LALA-032E-TAD LALA-032E-TAD 11560 15529 20084 R-404A C 3 5/8 1 1/8 20 460/60/3
BCLZ028VCC LALA-032E-TAC LALA-032E-TAC 11560 15529 20084 R-404A C 3 5/8 1 1/8 27 208-230/60/3
BCLZ028XC LALA-032E-TAC LALA-032E-TAC 11560 15529 20084 R-404A C 3 5/8 1 1/8 32 208-230/60/3
BCLZ0300B 2DF3-030E-CFB 2DF3-030E-CFB 14134 18469 23298 R-404A C 3 5/8 1 3/8 43 230/60/1
BCLZ0300C 2DF3-030E-TFC 2DF3-030E-TFC 14134 18469 23298 R-404A C 3 5/8 1 3/8 32 208-230/60/3
BCLZ0300E 2DF3-030E-TFD 2DF3-030E-TFD 14134 18469 23298 R-404A C 3 5/8 1 3/8 20 460/60/3
BCLZ030LC 2DF3-030E-TFC 2DF3-030E-TFC 14491 19672 25100 R-404A C 3 5/8 1 3/8 32 208-230/60/3
BCLZ030LCC 2DF3-030E-TFC 2DF3-030E-TFC 14491 19672 25100 R-404A C 3 5/8 1 3/8 34 208-230/60/3
BCLZ030RC 2DF3-030E-TFC 2DF3-030E-TFC 14134 18469 23298 R-404A C 3 5/8 1 3/8 39 208-230/60/3
BCLZ030VCC 2DF3-030E-TFC 2DF3-030E-TFC 14134 18469 23298 R-404A C 3 5/8 1 3/8 32 208-230/60/3
BCLZ030WC WJDL-0302-TFC 2DF3-030E-TFC 14500 19900 26400 R-404A C 3 1/2 1 1/8 30 208-230/60/3
BCLZ030YC 2DF3-030E-TFC
2DF3
-030E-TFC 14134 18469 23298 R-404A C 3 5/8 1 3/8 39 208-230/60/3
