Stanley Dura-Glide 5300 - Page 16

iQ Control Box
16 Document # 204144 REV B • www.stanleyaccess.com • 1.800.7.ACCESS
Copyright 2019, Stanley Access Technologies, LLC.
All rights reserved. Reproduction
in whole or in part without the express written permission of Stanley is prohibited.
01.25.2019
Index
Min
Value
Max
Value
Description Defaults
Single Dual
48
0 3 IO conguraon 0 0
TB2-5 TB2-7 TB2-9
00 (Default)
1 way / 2 way Reduced Access Control Pro acvaon override (highest priority
when selected).
4 Monitored Sensors (when selected).
Delay egress reset (default).
01 1 way / 2 way Reduced Fire Alarm.
02 1 way / 2 way Fire alarm Access Control Pro acvaon override (highest priority
when selected).
4 Monitored Sensors (when selected).
Delay egress reset (default).
03 Fire alarm Reduced Access Control Pro acvaon override (highest priority
when selected).
4 Monitored Sensors (when selected).
Delay egress reset (default).
IO Configuration Parameter Description
Allows the Fire Alarm to be used instead of funcons normally used with the selected input:
0 = Standard Funcons (NO Fire Alarm Input).
1 = Fire Alarm Input is TB2-9 (Removes Funcons: Access Control Pro acvaon override, Delayed Egress Reset,
and 4 Monitored Sensor capability).
2 = Fire Alarm Input is TB2-7 (Removes Reduced Open funcon).
3 = Fire Alarm Input is TB2-5 (Removes One-way funcon).
Index
Min
Value
Max
Value
Descriptions Defaults
Single Dual
49
0 99 Open Power
Assist Torque
This parameter sets the current to the motor which
is used to make the door feel easier to move open
when in “Manual” mode. This value should be
set only as high as is needed to reduce the force
required to move the door. Seng this value too
high can cause the door to move by itself.
Only available when index 11 is set to 02-ICU.
60 60
50 0 99 Close Power
Assist Torque
This parameter sets the current to the motor which
is used to make the door feel easier to move closed
when in “Manual” mode. This value should be
set only as high as is needed to reduce the force
required to move the door. Seng this value too
high can cause the door to move by itself.
Only available when index 11 is set to 02-ICU.
50 50
Table 3. Settings (continued)
