Resistance
1. Turn off all power and discharge capacitors on the circuit
under test.
2. Insert the red test lead in the “INPUT” jack and the black lead
in the “COM” jack.
3. Move the rotary switch to the “ Ω” position. Connect the
test leads across the circuit to be measured.
4. Read measured resistance on the LCD display.
Tips for Measuring Resistance
• Sometimes the resistor value and measured resistance differ.
This is due to the meter’s output test current goes through
all possible paths between leads.
• For low resistance measurements, short the test leads and
record the resistance displayed. Then connect to the circuit
and subtract the recorded resistance from the measurement
for the most accurate results.
• When leads are disconnected or measurement is out of
range, “OL” is displayed

WARNING: To avoid injury or damage to the meter, make
sure to turn off all power and discharge all capacitors
before measuring resistance.
Continuity
1. Turn off all power and discharge capacitors on the circuit
under test.
2. Insert the red test lead in the “INPUT” jack and the black lead
in the “COM” jack.
3. Move the rotary switch to the “ Ω” position. Connect the
test leads across the circuit to be measured.
4. Read measured resistance on the display. If the measured
resistance is less than 40Ω, the meter’s buzzer will sound.

WARNING: To avoid injury or damage to the meter, make
sure to turn off all power and discharge all capacitors
before measuring continuity
Frequency/Duty Cycle
1. Insert the red test lead in the “INPUT” jack and the black lead
in the “COM” jack.
2. Move the rotary switch to the “Hz%” position. Connect the
test leads across the circuit to be measured.
3. Read measured resistance on the display.
4. Read measured duty cycle on the display.
SPECIFICATIONS
General Specifications
Safety rating CAT III 600 V
Max. operating altitude 2000 m
Operating temperature 0~40 °C, <80 % RH
Storage temperature -10~60 °C, <70% RH (battery removed)
Coefficient 0.1 accuracy/°C
Max. voltage between terminals
and ground
600V DC or AC rms
Sample rate approx. 3 times/sec
Display
3 5/6 digit LCD (max. display: 5999/1999
(Resistance))
Over-range indication display only shows “OL”
Low battery indication
when battery voltage drops below operating
voltage, “~~~~~~” symbol appears on
the display
Polarity indication automatically displays “-”
Power 3 × 1.5 V AAA batteries
Dimensions 215 mm x 79 mm x 39 mm
Weight 195 g
Max. jawopening 26 mm
Technical Specifications
Accuracy: ±(% of reading + digits), 1 year warranty.
Ambient temp: 18°C~28°C, humidity: <75%.
Temperature coefficient: 0.1 accuracy/°C
(0°C~18°C or 28°C~40°C)
DC Voltage
Range
Resolution Accuracy
6 V
0.01 V
±(0.5% of reading + 3 digits)
60 V
0.1 V
600 V
1 V
• Input impedance: 10M
• Overload protection: 600V DC or AC rms
• Max. input voltage: 600V DC
NOTE: The minimum measurement of DC voltage and AC
voltage is >=1.
NOTE: When alternating current is detected at either the DC
voltage or the AC voltage shift, the LCD will display “ Err”.
AC Voltage
Range
Resolution Accuracy
6 V
0.01 V
±(0.8% of reading + 5 digits)
60 V
0.1 V
600 V
1 V
• Input impedance: 10MΩ
• Overload protection: 600V DC or AC rms
2. Press the trigger, insert the pincers red black pencil line into
the red and black air of the digital multimeter, open the
clamp and insert one conduc tor inside the jaws only clamp
one conductor multiple conductors with different current
directions will cancel out readings.
3. Read measured current on the LCD display.
