ENGLISH

FITTING THE PIN TAIL DEFLECTOR KIT

IMPORTANT - READ THE SAFETY WARNINGS LISTED IN THE PROSET XT1 AND PROSET XT2 INSTRUCTION

MANUAL CAREFULLY BEFORE PUTTING INTO SERVICE.

IMPORTANT - THE AIR SUPPLY MUST BE TURNED OFF OR DISCONNECTED BEFORE FITTING OR

REMOVING THE PIN TAIL DEFLECTOR KIT.

Refer to  g. 12 and the table 4 on page 9. Refer also to the ProSet XT1 and ProSet XT2 Service Manuals.

Item numbers in bold refer to  g. 12 and table 5, 6.

• The air supply must be disconnected.

• Install Ejector Assembly (TRM00494) and Return Spring (TP144-082).

• Screw End Cap (TP153-112) together with O-Ring (TP154-110), Ejector Guide (TP144-063).

• Fit Collector Adaptor (TP153-111) together with MCS Valve Pusher (TP144-142).

• Place Collector Adaptor Cover (TRM00033) over Collector Adaptor (TP153-111) and then install De ector

Adaptor (TRM00492) until the end face of Collector Adapter Cover (TRM00033) is secure against the

mating face of Collector Adapter (TP153-111).

• Fit De ector (PRG510-56) to De ector Adaptor (TRM00492).

Table 5 - TRM00305 - DEFLECTOR KIT for XT1

Item Part Number Description Qty

1 TRM00033 Collector Adaptor Cover 1

2 TRM00492 De ector Adaptor Assembly 1

3 PRG510-56 De ector 1

4 TRM00493 Ejector Assembly 1

Table 6 - TRM00306 - DEFLECTOR KIT for XT2

Item Part Number Description Qty

1 TRM00033 Collector Adaptor Cover 1

2 TRM00492 De ector Adaptor Assembly 1

3 PRG510-56 De ector 1

4 TRM00494 Ejector Assembly 1
