FITTING THE NOSE EXTENSION ASSEMBLY

IMPORTANT - READ THE SAFETY WARNINGS LISTED IN THE PROSET XT1 AND PROSET XT2 INSTRUCTION

MANUAL CAREFULLY BEFORE PUTTING INTO SERVICE.

IMPORTANT - THE AIR SUPPLY MUST BE TURNED OFF OR DISCONNECTED BEFORE FITTING OR

REMOVING THE SWIVEL HEAD NOSE ASSEMBLIES.

Refer to  g. 14 and Table 7, 8.

Table 7 - TRM00292 - EXTENSION KIT for XT1

Item Part Number Description Qty

1 TRM00001 Nose Housing 1

2 DPN239-006 Jaw Guide 1

3 PRG402-8A Jaw 1set

4 TP144-117 Jaw Pusher 1

5 TP144-118 Urethane Washer 1

6 TRM00010 Pulling Head Extension 1

7 TP144-113 Jaw Guide Lock 1

8 TP144-119 Jaw Pusher Spring 1

9 TP144-120 Mandrel Guide 1

10 TP144-114 Jaw Guide Lock Spring 1

11 TRM00011 Pulling Head Joint 1

12 DPN900-002 O-Ring 1

13 TRM00291 Jaw Pusher 1

14 TRM00290 Mandrel Guide Assembly 1

Table 8 - TRM00332 - EXTENSION KIT for XT2

Item Part Number Description Qty

1 TRM00003 Nose Housing 1

2 DPN275-001 Jaw Guide 1

3 71210-15001 Jaw 1set

4 TP144-050 Jaw Pusher 1

5 TP144-088 Urethane Washer 1

6 TRM00012 Pulling Head Extension 1

7 TP144-051 Jaw Guide Lock 1

8 TP144-081 Jaw Pusher Spring 1

9 TP144-052 Mandrel Guide 1

10 TP144-080 Jaw Guide Lock Spring 1

11 TRM00013 Pulling Head Joint 1

12 DPN900-002 O-Ring 1

13 TRM00355 Jaw Pusher for 4,5size 1

14 TRM00295 Mandrel Guide Assembly for 4,5size 1

Stanley ProSet XT2 Original Instruction
