Stanley ProSet XT2 Original Instruction

5
ENGLISH
Table 2 - RIGHT-ANGLE SWIVEL HEAD Capability
RIVET
TYPE
RIVET
DIAMETER
RIVET
MATERIAL
SWIVEL
HEAD
NOSE
TIP
DIMENSIONS
JAWS
AB
AVEX
AL. ALLOY
STEEL
AL. ALLOY
STEEL
AL. ALLOY
BULBEX
AL. ALLOY
AL. ALLOY
AVINOX
ST. STEEL
ST. STEEL
AVSEAL II
AL. ALLOY
AL. ALLOY
AL. ALLOY
AL. ALLOY
STAVEX
STEEL
STEEL
ST. STEEL
ST. STEEL


360 rotation
Fig. 3 Fig. 4
PREPARING THE BASE TOOL TO ACCEPT SWIVEL HEAD EQUIPMENT
IMPORTANT - READ THE SAFETY WARNINGS LISTED IN THE PROSET XT1 AND PROSET XT2 INSTRUCTION
MANUAL CAREFULLY BEFORE PUTTING INTO SERVICE.
IMPORTANT - THE AIR SUPPLY MUST BE TURNED OFF OR DISCONNECTED BEFORE FITTING OR
REMOVING THE SWIVEL HEAD NOSE ASSEMBLIES.
Refer to  g. 5 and  g. 6 and the table on page 7.
• The air supply must be disconnected.
• Rotate Collector Bottle Assembly (TRM00227) anti-clockwise and remove from Collector Adapter (TP153-
111).
• Unscrew and remove De ector Retaining Nut (TP144-064) together with Stem De ector (71213-05101).
• Remove Collector Adapter (TP153-111) together with MCS Valve Pusher (TP144-142), O-Ring (TRM00250)
from End Cap (TP153-112).
• Unscrew and remove End Cap (TP153-112) together with O-Ring (TP154-110), Ejector Guide (TP144-063).
