Drilling in masonry
Shift drill into 'Hammer mode'. Use carbide tipped masonry bits.
Refer to drilling section. Keep even force on the drill but not so
much that crack the brittle material. A smooth, even flow of dust
indicates the proper drilling rate.
LED work light
When drill is activated by pulling the trigger switch (1), the
integrated LED work light (8)will automatically illuminate the
work area.
Note: The work light is for lighting the immediate work surface
and is not intended to be used as a flashlight.
Bit tip storage
A bit storage slot (9) is built into the base of the tool.
MAINTENANCE
Your Stanley tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regular cleaning.
Your charger does not require any maintenance apart from
regular cleaning.
Warning! Before performing any maintenance on the tool,
remove the battery from the tool. Unplug the charger before
cleaning it.
• Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
• Regularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
• Regularly open the chuck and tap it to remove any dust
from the interior.
PROTECTING THE ENVIRONMENT
Separate collection. This product must not be
disposed of with normal household waste.
Should you find one day that your STANLEY product needs
replacement, or if it is of no further use to you, do not dispose
of it with household waste. Make this product available for
separate collection.
STANLEY provides a facility for the collection and
recycling of STANLEY products once they have
reached the end of their working life. To take
advantage of this service please return your product to any
authorised repair agent who will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local STANLEY office at the address
indicated in this manual. Alternatively, a list of authorised
STANLEY repair agents and full details of our after-sales
service and contacts are available on the Internet at:
www.2helpU.com.
Batteries
STANLEY batteries can be recharged many times.
At the end of their useful life, discard batteries with
due care for our environment:
• Run the battery down completely, then remove it from the
tool.
• NiCd, NiMH and Li-Ion batteries are recyclable. Take them
to any authorized repair agent or a local recycling station.
Notes
STANLEY’s policy is one of continuous improvement to our
products and as such, we reserve the right to change product
specifications without prior notice. Standard equipment and
accessories may vary by country. Product specifications may
differ by country.
Complete product range may not be available in all countries.
Contact your local STANLEY dealers for range availability
Troubleshooting
Problem Possible cause Possible solution
Unit will not start. Battery pack not
installed properly.
Battery pack not
charged.
Check battery pack
installation.
Check battery pack charg-
ing requirements
Unit starts immedi-
ately upon inserting
battery
The switch has
been left in the “on”
position.
The switch must be
moved to “off” to prevent
the tool from immediately
starting when battery is
inserted.
Battery pack will not
charge.
Battery pack not
inserted into charger.
Charger not plugged
in.
Surrounding air
temperature too hot or
too cold.
Insert battery pack into
charger until LED lights.
Plug charger into a work-
ing outlet.
Move charger and battery
pack to a surrounding air
temperature of above 40
degrees F (45ºC) or below
105 degrees F (+40.5ºC)
Unit shuts off
abruptly.
Battery pack has
reached its maximum
thermal limit.
Out of charge. (To
maximize the life of
the battery pack it is
designed to shutoff
abruptly when the
charge is depleted
Allow battery pack to cool
down.
Place on charger
and allow to charge.
(Original instructions) ENGLISH
9
