2. Forward/Reverse Button
3. Torque Adjust Collar
4. Dual Range Gear Selector
5. Keyless Chuck
6. Battery
7. Battery Release Button
8. LED Work Light
9. Bit Tip Holder
INTENDED USE
This drill/driver is designed for light fastening and drilling
applications.
DO NOT use under wet conditions or in presence of flammable
liquids or gases.
This drill/driver is a professional power tool.
DO NOT let children come into contact with the tool. Supervision
is required when inexperienced operators use this tool.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities, or for lack of experience and/or for want of
knowledge or skills unless they are supervised by a person
responsible for their safety. Children should never be left
alone to play with this product.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of your mains.
Your STANLEY charger is double insulated in
accordance with EN 60335; therefore no earth wire
is required.
If the supply cord is damaged, it must be replaced by a
specially prepared cord available through the STANLEY service
organisation.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1 mm
2
; the maximum length is 30 m.
When using a cable reel, always unwind the cable completely.
Assembly and adjustments
WARNING: Prior to assembly and adjustment,
always remove the battery pack. Always switch
off the tool before inserting or removing the
battery pack.
WARNING: Use only STANLEY battery packs
and chargers.
Inserting and Removing the
Battery Pack from the Tool (g. 3)
WARNING: To reduce the risk of serious
personal injury, place the forward/reverse
button in the lock-off position or turn tool off
and disconnect battery pack before making
any adjustments or removing/installing
attachments or accessories. An accidental
start-up can cause injury.
NOTE: Make sure your battery pack (g) is fully charged.
TO INSTALL THE BATTERY PACK INTO THE TOOL
HANDLE
1. Align the battery pack with the rails inside the handle.
2. Slide it firmly into place until you hear the lock snap into
place.
TO REMOVE THE BATTERY PACK FROM THE TOOL
1. Press the release button (f) and firmly pull the battery
pack out of the tool handle.
2. Insert battery pack into the charger as described in the
charger section of this manual.
OPERATING INSTRUCTIONS
Safety warnings and instructions: Drills
@
WARNING! Before using tool, read all
instructions and cautionary markings on tool.
@
WARNING! Drill may stall (if overloaded or
improperly used) causing a twist. Always
expect the stall. Grip the drill firmly with
two hands to control the twisting action and
prevent loss of control which could cause
personal injury. If a stall does occur, release
the trigger immediately and determine the
reason for the stall before re-starting.
Trigger switch & forward/reverse button (Fig. D)
f The drill is turned ON and OFF by pulling and
releasing the trigger switch (1) shown in Fig. D. The
farther the trigger is depressed, the higher the speed
of the drill.
f A forward/reverse control button (2) determines the
rotational direction of the tool and also serves as a lock off
button.
