TT46 User Manual ◄ 17
Item Part No. Qty Description
1
03972
47436
1
Female Coupler (Parker)
Female Coupler (Aeroquip)
2
03973
47437
1
Male Coupler (Parker)
Male Coupler (Aeroquip)
3 02900 2 Roll Pin
4
56725
66727
2
Hose Assy (Parker)
Hose Assy (Aeroquip)
5 12832 1
Orice Plug (not used in
TT46233)
6 01605 2 O-Ring (Incl with Item 4)*
7 04058 1 Spring
8 20515 1 Valve Spool
9 04057 1 Bushing
10 00293 1 O-Ring*
11 01362 1 O-Ring*
12 04056 1 Rod Wiper*
13 07493 1 Plug
14 20499 1 Charge Valve
15 02494 2 Handle Grip
16 28369 1 Handle
17 20500 2 Spirol Pin
18 20511 1 Lever
19 28494 1 Top Plate
20 04374 4 Locknut
21 20502 1 Trigger
22 58529 1 Trigger Handle
23 20498 2 Spring
24 20505 1 Handle Pivot
25 20508 2 Pivot Screw
26 07479 1 Accumulator Diaphragm
27
12833
04385
1
Piston
Piston (TT46233 & 233B Only)
28
17784
07589
1
Sound Power Level Sticker (CE
Models Only)
GPM Sticker (TT46113,
TT4612303 Only)
29 28409 1 Composite Sticker
30 04605 4 Push Pin
31 11588 1 Accumulator Charge Block
32
07485
04384
1
Flow Sleeve
Flow Sleeve (TT46233 &
TT46233B Only)
33 28322 1 CE Sticker
34 11206 1 Circuit Type C Sticker (CE Only)
35 04381 2 Backup Ring*
36 04379 2 O-Ring*
37 04378 1 Porting Block
38
07480
04380
1
Automatic Valve Body
Automatic Valve Body (TT46233
& TT46233B Only)
39 74679 1 Name Tag (5-GPM Models)
74680 1 Name Tag (10-GPM Models)
40 04571 2 Push Pin
Item Part No. Qty Description
41 04382 1 Automatic Valve
42 12307 2 Nut
43 12148 2 Spring
44 04383 1 Flow Sleeve Tube
45 73680 1 Railroad Help Desk Sticker
46 32258 1 Bit Keeper
47
32249
38008
1
Bit Guide (Pair) Hex Shank
Bit Guide (Pair) Round Shank
(TT46133/133B/ 133C/133UP/
TT46233/TT46233B Only)
48
44937
59033
1
Tie Tamper Bit
Tie Tamper Bit (TT46133/
TT46233/TT46233B Only)
49 15400 1 Hex Bushing
50
31955
65046
1
Lower Body
Lower Body (TT46233 &
TT46233B Only)
51 02022 1 O-Ring*
52 04387 1 Rod Wiper*
53 04780 1 Washer
54 04386 1 Cup Seal*
55 25304 2 Capscrew
56 20517 4 Side Rod
57 72919 2 Filler (Yellow) Snap-On
58 23147 1
Lower Body (TT46113/
TT46113C Only)
59 371500 2
ESNA Nut (TT46113/TT46113C
Only)
60 44937 1
Tie Tamper Steel (TT46113/
TT46113C Only)
61 21028 1
Bit Retaining Top Spring (Guide
Pair) (TT46113/TT46113C Only)
62 21029 1
Compression Coil Spring
(TT46113/TT46113C Only)
63 15411 1
Bit Retaining Spring (Guide
Pair) (TT46113/TT46113C Only)
64 22890 1
Bit Keeper Weldment (TT46113/
TT46113C Only)
65 371050 2
Washer (TT46113/TT46113C
Only)
66 15630 2
Capscrew (TT46113/TT46113C
Only)
67 74832 2
Stanley Logo Decal (Attaches to
Filler item 57)
68 33037 1
Lower Body Assy (TT46133
only, Incl 49 & 50)
SK 04595 1
SEAL KIT (* Denotes part in
seal kit)
Lower Body Assy Part No., 33037. Includes Items 49-50.
Tie Tamper Update Kit: Part No. 33038. Includes Items 42-
43, 46-47, 49-55
Coupler Sets: Aeroquip 47438 / Parker 03971
TT46113/133/233 PARTS LIST
