Stanton RM-406 - Master, Zone, and Booth Output Adjustments

RM.406 Top Panel (FUNCTIONS)
Section C: Output Controls
C
LR
6 7 8
9
1011
6. Master Level: Controls the overall output level of the audio signal sent
through the Master connectors (see Output Connections.)
7. Stereo/Mono Switch: Switches the Master output between a stereo or
mono signal. Mono mode can be used to accommodate some large PA sys-
tems. It can also be engaged in the event of a sudden loss of stereo
signal in phonograph cartridge connections [Stereo = UP position.]
8. Zone Level: Controls the output level of the audio signal sent through the
Zone connectors (see Output Connections.)
9. Booth Level: Controls the output level of the audio signal sent through the
Booth Output connectors (see Output Connections.)
10. Master Pan: Controls left/right signal balance of the Master Output (#6.)
11. Crossover LED: When lit, this indicates that the Crossover is active (for
setting the Crossover see Output Connections.)
