• If using automatic feed, when one piece of tape is removed, the unit will automatically feed
and cut the next piece at the preset length.
• The tape length is easily seen on the LED display, and operation is simple — press the CM
key or MM key to set the length (Setting limit: 20mm to 999mm).
• If a piece of long tape is needed, press FEED key for desired length, then press CUT key
to cut.
• The blade unit can be removed and replaced easily. (Tape jamming is also easily fixed by
removing the blade unit.)
FEATURES
NOTES
Do not use volatile liquids
(thinner, benzine, etc.) to
clean the dispenser. Wipe
with dry cloth only.
Do not use the tape
dispenser in humid or dusty
places.
Do not insert your fingers
into the tape outlet!
Do not leave the tape
dispenser in direct
sunlight.
Do not drop the tape
dispenser or subject it to
heavy shocks.
Do not insert bars or plates
into the tape outlet – this
will damage the blade.
Part Number Description Drawing
ZCM1000P517
Roller Pressure
Unit 2
ZCM1000P518 Front Holder 3 Unit
ZCM1000P519 Front Holder 3
ZCM1000P520 Cut Lever Pressure 2
ZCM1000P521 Cut Lever Liner 2
ZCM1000P522 Cut Lever Shaft Collar
ZCM1000P523 Cut Lever Unit 2
ZCM1000P526
Open Set
Knob & Spring
ZCM1000P527 Pinion Gear Stopper
ZCM1000P528 Pinion Gear Unit 2
ZCM1000P533
Separating Roller
Holder Unit
