StarTech.com IPUSB2HD2 User Manual

Instruction Manual
1
Introduction
The IPUSB2HD2 HDMI® over IP Extender delivers a versatile HDMI-IP link between PCs on your
network and an HDMI monitor/projector, at full high denition (1080p, 1920 x 1080) video
resolution. Accompanying audio signals are transmitted directly through the HDMI output, or
separately through the built-on 3.5mm stereo output port.
An ideal solution for sharing a display or projector over an Ethernet network so that even PCs
lacking digital video output can still connect, the IP/HDMI adapter can communicate through
a network router at transmission distances up to 100m (300ft). Plus, it oers 2 USB 2.0 ports
on the display side, to connect and share peripherals such as USB storage or keyboard/mouse
input with the connected PC.
Alternatively, the device can be used directly connected as a USB to HDMI adapter.
Packaging Contents
• 1 x HDMI over IP converter
• 1 x Universal Power Adapter (NA/UK/EU)
• 1 x Driver CD
• 1 x Instruction Manual
System Requirements
• HDMI enabled display device with HDMI cable
• Available AC electrical outlet
• Minimum CPU: Intel®/AMD® 2.4 GHz single core
• Minimum RAM: 1GB
• Microsoft® Windows® XP (32-bit), Vista/7 (32/64-bit)
• USB Mode: USB mini-B to USB type A male/male cable
or
Ethernet Mode: RJ45 terminated Cat5/Cat6 UTP Ethernet cabling

StarTech.com IPUSB2HD2 Specifications

General

Type	AV transmitter
Audio system	-
Product color	Black
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Maximum transfer distance	100 m
Supported graphics resolutions	1920 x 1080 (HD 1080)
DC-in jack	Yes
RJ-45 input ports	1
Storage temperature (T-T)	0 - 85 °C
Operating temperature (T-T)	0 - 70 °C
Operating relative humidity (H-H)	10 - 80 %
Current	2 A
Operating voltage	5 V
Package depth	225 mm
Package width	150 mm
Package height	60 mm

Weight and Dimensions

Weight	460 g
Dimensions (WxDxH)	71 x 132 x 28 mm
