StarTech.com IPUSB2HD2 User Manual

Instruction Manual
8
How to Use
Conguring the image being displayed by the monitor that is connected to the HDMI Video
Adapter, can be done in one of two ways:
1. Accessing the Windows Display Settings
• Windows XP: right-click on a blank area of the desktop,
select Properties, then click on the Settings tab:
• Windows Vista: right-click on a blank area
of the desktop, select Personalize, then
select the Display Settings option.
• Windows 7: right-click on a blank area of the
desktop, select Screen Resolution.
2. Right-clicking the DisplayLink tray icon ( ) in the system notication area.

StarTech.com IPUSB2HD2 Specifications

General

Type	AV transmitter
Audio system	-
Product color	Black
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Maximum transfer distance	100 m
Supported graphics resolutions	1920 x 1080 (HD 1080)
DC-in jack	Yes
RJ-45 input ports	1
Storage temperature (T-T)	0 - 85 °C
Operating temperature (T-T)	0 - 70 °C
Operating relative humidity (H-H)	10 - 80 %
Current	2 A
Operating voltage	5 V
Package depth	225 mm
Package width	150 mm
Package height	60 mm

Weight and Dimensions

Weight	460 g
Dimensions (WxDxH)	71 x 132 x 28 mm
