Instruction manual
5
Blinks for a brief
time
The emulated mouse is moving or an emulated key is being
pressed.
Blinking
constantly
A problem with the USB connection to the server is occurring.
For example, the server is disconnected or the host’s operating
system isn’t enumerating the USB device.
Server VGA LED
LED behavior Scenario
Solid light A valid VGA video signal is being received.
No light Nothing is connected or the system has entered power-saving
mode.
Blinking You’re trying to use an unsupported video mode or there is a
problem with the video signal.
Note: Regardless of the video input status, the server VGA LED won’t illuminate until
the adapter has been connected to the application software at least once.
User console link and activity LED
LED behavior Scenario
Solid light A good connection to the laptop is established.
Blinking
constantly
The USB connection to the laptop is lost or ignored, or was
never established.
Blinks for a brief
time
Video data is being sent to the laptop.
Using the crash cart adapter
When the crash cart adapter is connected, the real-time video from the attached host
computer is displayed and centered in the main window.
About the toolbar
There is a toolbar displayed along the top edge of the window. You can hide, detach,
or drag the toolbar onto the other three edges of the window. This toolbar includes
