Instruction Manual
29
Specications
Number of input Ports 4
Number of output Ports 8 (4x HDMI / 4x CAT5)
Connectors
4 x HDMI female (A/V input)
4 x HDMI female (A/V output)
4 x RJ-45 female (A/V output)
1 x RJ-J5 female (LAN Control)
1 x DB-9 female (Serial Control)
1 x IRDA (Infrared) Female (3.5mm)
1 x DC Power
LEDs
1 x Power/Signal Input
4 x Output 1 Display Selection
4x Output 2 Display Selection
4x Output 3 Display Selection
4x Output 4 Display Selection
1x Output 1 UPT Activity (rear)
1x Output 2 UPT Activity (rear)
1x Output 3 UPT Activity (rear)
1x Output 4 UPT Activity (rear)
1x LAN Activity (Rear)
Max. Resolution 1920x1200 / 1080p
Max. CAT5 Cable Length 230ft (70m)
Audio Support Yes
EDID Support Yes
