Fault Cause Remedy
Load cannot be
operated
+
info LED flashes
red
+
2. green LED
flashes
•Load output is switched
off due to excessive battery
voltage
The load output automati-
cally switched on again as
soon as the battery voltage
lies within the permissible
range
•External charging source is
not voltage-limited
X Check the external charging
source
X If necessary, switch off
external charging sources
X Charge Controller reset:
Disconnect the load,
disconnect the module and
disconnect the battery.
Then in reverse order Clamp
(battery -> Module -> and
finally the load)
Load cannot be
operated
+
info LED illumi-
nates green
•Defective load or installa-
tion error
X Connect load correctly
X Replace load
Battery is not
charged
•Solar module not connected
X Connect the solar module
•Solar module connected
with incorrect polarity
X Connect the solar module
with the correct polarity
•Short circuit at solar module
input
X Correct the cause of the
short circuit
•Incorrect solar module
voltage
X Use a solar module of the
specified voltage
•Device overheated
X Make sure the device is well
ventilated
•Solar module defective
X Replace the solar module
Battery display
jumps quickly
•Large pulse current
X Tune the current consump-
tion to match the battery
capacity
•Battery is defective
X Replace the battery
