17
730927 | Z04 | 1440
9. Technical data
MPPT 1010 MPPT 2010
Characterisation of the operating behaviour
System voltage 12 V (24 V)
Rated output 125 W (250 W) 250 W (500 W)
Max. efficiency > 98 %
Own consumption 10 mA
DC input side
MPP voltage 15 V (30 V) <
U
module
< 75 V
15 V (30 V) <
U
module
<< 100 V
Open circuit voltage solar module
(at minimum operating temperature)
17 V ... 75 V
(34 V ... 75 V)
17 V ... 100 V**
(34 V .. 100 V)**
Module current 9 A 18 A
DC output side
Charging current 10 A 20 A
Load current 10 A
End-of-charge voltage* 13.9 V (27.8 V)*
Boost charge voltage* 14.4 V (28.8 V)*
Equalisation charging* 14.7 V (29.4 V)*
Reset voltage* (SOC / LVR) > 50 % / 12.5 V (25.0 V)*
Deep discharge protection* (SOC / LVD) < 30 % / 11.5 V (23.0 V)*
Application conditions
Ambient temperature -25 °C … +40 °C
Equipment and design
Terminal clamps (fine-wire / single wire) 16 mm
2
/ 25 mm
2
- AWG 6 / 4
Degree of protection IP 32
Dimensions (X x Y x Z) 187 x 153 x 68 mm
Weight approx. 900 g
*
see the chapter “Options” page 13 Technical data at 25 °C / 77 °F
.
** CAUTION
X If an open circuit voltage of more than 100 V is supplied to the connected solar
module, the controller will be destroyed. When selecting the solar module, it
is important to bear in mind that the open circuit voltage should never exceed
100 V over the entire working temperature range.
X When using solar modules with a maximum open circuit voltage of between
75 and 100 V (over the entire temperature range), all installation steps must be
carried in accordance with protection class II.
