6 Structure
6.1 Casing
11
13
2
16
15
14
ESC
SET
No. Element
See
Section

Mode button (under
front panel)
7.1
8

Operating buttons , SET,
ESC, 
7.1

Display 6.2

Front panel 4.1

Terminal cover 4.3.1
1)

Terminal cover fastening
screw
–
1)
Section 4.3.1 describes the terminals under the
terminal cover.
Fig. 7: Front view of the controller
6.2 Display
6.2.1 Overview
B
l
g
p
Fig. 8: Overview of the display areas (all elements visible)

System graphics

Settings menu

Pictograms for functions

Operational and setting values
The display areas are described below.
