12x
7.5 Nm
(66.38 in-lbs)
4 3
2
1
3
4
Page 15 of 29
P/N 1411856001
Doc # 152667 Rev C
Alternative Base Assembly
Assemblage de base alternatif
Ensamblaje de base alternativa
