Preparing the setup location
1. Set up the heat pump
1
exactly as it will be installed later.
2. Lay the hoses from the water treatment system to the setup location of the heat pump (see Fig. E).
Make sure that there is no tension on any of the lines routed to the heat pump and that they are not
in the way.
D
3065 mm
2100 mm
300 mm
700 mm
2500mm
700 mm
E
36
