Panel Controls and Terminals
UR242 Operation Manual 13
Dedicated Windows for Cubase Series
These are the windows for configuring the device settings
from Cubase series software. The dedicated windows for
Cubase series allow you to configure the parameters which
are configured by dspMixFx UR242. Two types of windows
are available: Input Settings and Hardware Setup.
Input Settings Window
This window is for configuring the input settings of the
device. The signal flow is from top to bottom. The settings
on this window (except for the +48V indicator) are saved to
the Cubase project file.
Input setting window ([HARDWARE]) is shown according
to the settings for Stereo bus and Mono bus at the UR242
device port.
How to Open the Window
The Input Settings window appears in the Mixer window.
1.
[Devices]
[MixConsole] to open the Mixer window.
2. Click [Racks] to open the rack selector.
The rack selector appears.
3. Click next to the [Hardware] to show
[HARDWARE] in the Mixer window.
Hidden Visible
I
4. Click [HARDWARE].
The Input Settings window appears in the Mixer
window as shown below.
To Next Page
