20
If you are in any doubt, identify the conductors using a voltage tester; then disconnect
from the power supply again. Connect phase (L), neutral (N) and protective-earth
conductor (PE) to the terminal.
Important:
Incorrectly wired connections will produce a short circuit later on in the product or
fuse box. In this case, you must identify the individual conductors once again and re-
connect them. A mains power switch for turning the unit ON and OFF may of course
be installed in the mains supply lead.
Interconnection
" " used for interconnecting lights. As many as 10 lights of this type can be connected
in parallel. (Fig. 4.1)
5. Mounting
• Check all components for damage.
• Do not use the product if it is damaged.
• When installing the light, make sure the installation site is not subject to vibration.
• Select an appropriate mounting location, taking the reach and motion detection
into consideration.
The most reliable way to detect movement is given by mounting the light to point
across the direction in which people walk and by making sure no obstacles (e.g.
trees, walls etc.) interrupt the line of sensor vision.
Mounting procedure
• Switch OFF power supply. (Fig. 4.1)
• Undo locking screw and detach light enclosure from wall mount. (Fig
5.1
)
• Detach plug-in terminal and remove light enclosure from wall mount. (Fig.5.2)
• Mark drill holes. (Fig. 5.3)
• Drill holes and fit wall plugs. (Fig. 5.4)
• Concealed mounting. (Fig. 5.5)
• Surface-mounted installation with spacers. (Fig. 5.6)
• Attach retaining strap to the wall mount and fit plug-in terminal. (Fig.
5.7
)
• Connect conductors. (Fig. 5.8)
• When interconnecting several lights, break out safety tab. (Fig.5.8)
• Fit light enclosure onto wall mount. (Fig. 5.9)
• Screw in locking screw. (Fig. 5.9)
• Switch ON power supply. (Fig. 5.9)
• Make settings ➜ "6. Function"
