STEINEL Spot ONE - Electrical Connection

19
Non-intended use
– The LED light cannot be dimmed.
Not dimmable
Spot ONE package contents (Fig. 3.1)
– Light
– Three screws
– Three ground plugs
– Three spacers
Spot DUO package contents (Fig. 3.2)
– Light
– Four screws
– Four wall plugs
– Four spacers
Product dimensions
Spot ONE (Fig. 3.3)
Spot DUO (Fig. 3.4)
Product parts (Fig. 3.5)
A Wall mount
B Connecting terminal
C Locking screw
D Light base
E Light enclosure
F Twilight setting (Spot ONES / DUOS only)
G Time setting (Spot ONES / DUOS only)
Spot ONES / DUOS detection zone (Fig. 3.6-3.8)
Luminous intensity distribution (Fig. 3.9)
4. Electrical connection
Wiring diagram (Fig. 4.1)
The supply lead is a three-core cable:
L = phase conductor (usually black, brown or grey)
N = neutral conductor (usually blue)
PE = protective-earth conductor (green/yellow)
